$70.00
Ebook format of the GeoTol Pro 2020 Fundamentals Workbook. Based on the latest ASME Y14.5-2018 Standards. Access is through our GeoTol U portal and is not available for download.
The GeoTol Pro 2020 Workbook in electronic format. Based on the latest ASME Y14.5-2018 Standards. 400 pages, full color. This geometric dimensioning and tolerancing eBook flips like a real book and offers access 24-7 wherever you have an internet connection. Access through our GeoTol U portal is not available for download.
| Unit 1 | Introduction – Symbols and Terms |
| Unit 2 | Limits of Size |
| Unit 3 | How the Geometric System Works |
| Unit 4 | The Datum Reference Frame |
| Unit 5 | The Three Product Plans and Position Inspection |
| Unit 6 | Orientation Tolerances and the Hierarchy |
| Unit 7 | Virtual Condition and Material Boundary Modifiers |
| Unit 8 | The DRF II – Datum Targets and Irregular Surfaces |
| Unit 9 | The DRF III – Advanced Concepts |
| Unit 10 | Form Tolerances |
| Unit 11 | Profile Tolerances |
| Unit 12 | Position Tolerances |
| Unit 13 | Coaxial Controls |
| Unit 14 | Application Exercises |
| Appendix A | Part 1 – Principle Changes and Additions in the ASME Y14.5-2018 from 2009
Part 2 – Principle Changes and Additions in the ASME Y14.5-2009 from 1994 |
| Appendix B | Differences between the ASME Y14.5 and ISO-GPS standards |
